Metallic Megnetic Drive Pumps

Get a Price/Quote

MOQ : 1 Unit

Metallic Megnetic Drive Pumps Specification

Control System
DOL / Star-Delta Starter

Inlet/Outlet
3/4 to 4 BSP/NPT/Flanged

Features
Leak-Free Design, Resistant to Corrosion, Low Maintenance

Mounting Type
Base Mounted

Discharge Pressure
Up to 10 Bar

Frequency
50 Hz / 60 Hz

Noise Level
<75 dB

Max Suction
6 mtr

Flow Rate
Up to 60 m3/hr

Caliber
19 mm - 100 mm

Speed
2900 rpm / 3500 rpm

Voltage
220V / 380V / 415V

Working Temperature
-10C to 120C

Head Size
Up to 45 m

Theory
Centrifugal Pump

Material
SS304, SS316, Alloy-20, Hastelloy-C

Structure
Single Stage, Close Coupled

Power
0.37 kW to 15 kW

Standard
ISO 2858 / DIN 24256

Fuel Type
Electric

Pressure
Max. 10 Bar

Usage
Chemical Transfer, Acid Handling, Pharmaceutical & Petrochemical Industries

Application
Corrosive Liquid Handling

Suction Type
End Suction

Seals Type
Seal-less Magnetic Drive

Priming
Self-Priming / Non-Self-Priming available

Pump Type
Magnetic Drive Pump

Capacity
1 m3/hr to 60 m3/hr

Impeller Type
Closed / Semi-Open

Connection
Threaded / Flanged

Optional Accessories
Variable Frequency Drive, Base Frame, Coupling Guard

Rotation
Clockwise When Viewed from Drive End

Bearing
PTFE / Ceramic / Carbon

Motor Cooling
TEFC (Totally Enclosed Fan Cooled)

Ambient Temperature Limit
Up to 50C

Installation Position
Horizontal

Protection Class
IP55

Metallic Megnetic Drive Pumps Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About Metallic Megnetic Drive Pumps

Order now to secure tremendous value with our limited-time offer on Metallic Magnetic Drive Pumps-a crackerjack solution designed for grandiose industrial needs. Engineered for transcendent performance, these pumps boast robust SS304, SS316, Alloy-20, or Hastelloy-C construction and a seal-less magnetic drive for leak-free, low-maintenance operation. Withstanding temperatures from -10C to 120C and flows up to 60 m3/hr, they are ideal for corrosive liquid, acid, and chemical transfer. Featuring state-of-the-art PTFE, ceramic, or carbon bearings, each pump promises resilient, quiet, and reliable operation under the harshest working conditions.

Special Features & Competitive Advantages

Metallic Magnetic Drive Pumps stand out with their premium leak-free, seal-less design, superior corrosion resistance, and low maintenance demands. These pumps accommodate self-priming or non-self-priming options, ISO/DIN standards, and a versatile range of inlet/outlet connections. Tailored for chemical, acid, and pharmaceutical applications, their grandiose adaptability, robust safety features, and compatibility with advanced control systems make them a transcendent choice for high-stake operations where reliability is paramount.

Sample Policy, Payment, and Delivery

Samples of the Metallic Magnetic Drive Pumps are provided upon quotation approval and are typically handed over after confirmation of payment terms, which include flexible options for both advance and milestone payments. Freight is calculated based on destination, and delivery time is minimized through our dedicated logistics network. Expect prompt shipment after order finalization, ensuring secure and efficient delivery. Contact us to discuss tailored freight arrangements or to request a detailed quotation for your application.

FAQ's of Metallic Megnetic Drive Pumps:

Q: How do I select the appropriate Metallic Magnetic Drive Pump for my application?

A: To select the right pump, consider the required flow rate, head, working temperature, chemical compatibility, and installation specifications. Our experts can help match the pump to your process needs.

Q: What are the advantages of using a magnetic drive pump compared to traditional sealed pumps?

A: Magnetic drive pumps are leak-free, require less maintenance, withstand corrosive environments, and offer enhanced safety due to the seal-less design, making them ideal for handling hazardous or toxic liquids.

Q: Where can these pumps be installed and in which industries are they most commonly used?

A: These pumps are installed horizontally and are commonly applied in chemical transfer, acid handling, petrochemical, and pharmaceutical industries throughout India due to their corrosion-resistant features.

Q: What is the process for ordering and receiving a sample unit?

A: To obtain a sample, submit your application details for a quotation. Once the terms are agreed and payment is made, your sample will be promptly handed over and shipped as per our delivery policy.

Q: When can I expect my pump to be delivered after placing an order?

A: Delivery times depend on order specifications, location, and availability. However, shipments are typically processed quickly after order confirmation and payment, with freight details communicated during quotation.

Q: What optional accessories are available with these pumps?

A: Optional accessories include a variable frequency drive, base frame, and coupling guard, allowing for enhanced operational versatility and safety tailored to your installation.
